1. IP65, Waterproof、Dustproof.
2. Aluminium surface shell and cast iron bottom case design for anti vandal
3. High quality voice communication wit
Key Features:
● IP door phone One key to dial emergency call for help, realize the bi-directional full-duplex voice intercom.
● IP door phone Panel adopts advanced wire drawing aluminium alloy material,high strength damage resistant button, strong and durable.
● Support POE power supply and the external power supply.
● Embedded wall or mounted in the wall, to avoid cable leakage users, to ensure that the internal network information security, provide and remote configuration.
● Built-in speaker and high sensitive microphone, support hand-free calls and receive emergency broadcast
● Adopted seal design, waterproof and dustproof level is IP65.
● IP door phone supports extra access security device, multi-functions provide more perfect service to industry customers. Phone Features:
● WEB support Multi-Language
● 1 SIP account, Hotline
● Call hold, Call waiting, Call forward
● Call transfer (blind/busy/ask)
● Mute, DND
● Auto-answer, 3-way conferencing
● 1 DSS programmable key(Speed dial, Intercom etc.)
● Volume control
● Direct IP call without SIP proxy
● Default Ring tone 1 selection/import/delete
● Custom Warning Ring tone 2 selection/import/delete
● Time setting(SNTP/SIP Server/Manual)
● IP door phone supports SIP main/standby server Advanced Features:
● 1 key to restore the factory value
● 1 DSS programmable key(Speed dial, Intercom etc.)
● IP door phone has 2 input and 2 output control interface, can connect other security equipment
● 1 recording interface, 1 custom warning ring tone interface(using Ring tone 2)IP PBX System Integration:
● Busy lamp field (BLF), BLF list
● Bridged line appearance (BLA)
● DND & Forward synchronization
● Intercom, Paging, Music on hold
● Call pickup, Dial Plan, Call recording Anonymous call, Anonymous call rejection Codes and Voice Features:
● Wideband Codec: G.722
● Narrowband codec: G.711μ/A, G.723.1
● G.726, G.729a/b, iLBC
● VAD, CNG, AEC, AGC
● Full-duplex, Security:
● LLDP, VLAN QoS (802.1pq),VPN(L2TP)
● Transport Layer Security (TLS)
● Digest authentication using MD5/MD5-sess
● Secure configuration file via AES encryption
● Phone lock for personal privacy protection
● Admin/User 2-level configuration mode Network Features:
● SIP v1 (RFC2543), v2 (RFC3261)
● DNS SRV (RFC3263)
● NAT Traversal: STUN mode
● DTMF: In-Band, RFC2833, SIP Info, Auto
● IP door phone has HTTP/HTTPS Web Management
● IP Assignment: Static/DHCP/PPPoE
● IP door phone has network support Bridge mode
● TFTP/DHCP/PPPoE client
● DNS client, NAT/DHCP serverManagement:
● IP door phone has auto-provision via FTP/TFTP/HTTP/HTTPS
● SNMP V1/2 , TR069 optional
● Configuration: browser/phone/auto-provision
● Trace package and system log exportPhysical Features:
● 1 DSS programmable key(Speed dial, Intercom etc.)
● 1 LED lights,
● 1 light touch button(Remote factory value)
● 1xRJ45 10/100M Ethernet ports
● Power adapter: AC 100~240V input and
● DC 12V/1A output
● Power over Ethernet ,IEEE 802.3af,class 0
● Net weight: 0.52KG, Gross weight: 0.65KG
● Dimension: 162x112x40MM
● Operating humidity: 10~95%
● Storage temperature: up to 60°CCertifications:
● RoHS、CE、FCC |
|
